L-Acoustics Line Array System – W-210A Satellite & W-250A Sub-Bass Modules

L-Acoustics Line Array System – W-210A Satellite & W-250A Sub-Bass Modules

KSh4,500,000.00
KSh4,500,000.00
Sale Sold out
Shipping calculated at checkout.

Product Description

The L-Acoustics Line Array System combines the W-210A two-way satellite module and the W-250A sub-bass module to deliver clear, powerful sound coverage for tours, festivals, and permanent installations. Each W-210A features dual 10″ neodymium woofers and dual 2″ titanium-diaphragm compression drivers in a rugged birch-ply enclosure with water-proof, wear-resistant black paint. The companion W-250A sub-bass adds two 15″ neodymium woofers in a deeper cabinet to extend low-frequency response down to 40 Hz. Both modules offer high power handling, efficient dispersion control, and NL8 connectivity for seamless rigging and system scalability.


Key Features

  • Satellite & Sub Integration Seamless pairing of W-210A satellites with W-250A sub-bass modules for full-range coverage.

  • Rugged Construction Birch plywood enclosures with water-proof, wear-resistant textured black finish.

  • High-Power Handling W-210A: 600 W LF/160 W HF RMS; W-250A: 1 200 W LF RMS, 2400 W peak.

  • Efficient Dispersion W-210A: 110° horizontal × 9° vertical coverage for precise audience targeting.

  • Neutrik NL8 Connectivity Dual NL8 input connectors for secure, high-current array wiring.

  • Lightweight Neodymium Transducers Low weight for easier handling and reduced load on flying hardware.


Technical Specifications

Specification W-210A Satellite Module W-250A Sub-Bass Module
LF Transducers 2 × 10″ neodymium woofers (75 mm coil) 2 × 15″ neodymium woofers (100 mm coil)
HF Transducers 2 × 2″ neodymium drivers (51 mm diaphragm) N/A
Frequency Response 60 Hz – 20 kHz (±3 dB) 40 Hz – 150 Hz (±3 dB)
Power Handling (RMS) LF: 600 W / HF: 160 W LF: 1 200 W
Power Handling (Peak) LF: 1 200 W / HF: 320 W LF: 2 400 W
Sensitivity (1 W/1 m) LF: 99 dB / HF: 108 dB 112 dB
Max SPL (Peak @1 m) LF: 127 dB / HF: 127 dB 143 dB
Nominal Impedance 16 Ω 4 Ω
Coverage Pattern 110° H × 9° V Omni
Connectors 2 × NL8 Speakon® 2 × NL8 Speakon®
Enclosure Birch plywood, textured black paint Birch plywood, textured black paint
Dimensions (W×H×D) 855 × 293 × 600 mm 855 × 440 × 820 mm
Weight 42 kg 72 kg
