Behringer S32 32×16 Digital Stage Box
Behringer S32 32×16 Digital Stage Box
Share
Couldn't load pickup availability
Product Description
The Behringer S32 is a high-performance digital stage box offering 32 remote-controllable Midas-designed mic preamps and 16 balanced XLR line outputs via a single Cat5e cable. It features AES50 networking with Klark Teknik SuperMAC technology for ultra-low-latency, rock-solid audio transport, plus Ultranet integration for Powerplay P16 personal monitors. Rack-mountable in a compact 1U chassis, the S32 brings professional-grade I/O anywhere from front-of-house racks to stage wings.
Key Features
-
32 remote-controllable Midas-designed mic preamps with +48 V phantom power LEDs and switchable –20 dB pad
-
16 balanced, relay-protected XLR line outputs for flexible routing
-
Single AES50 network port with Klark Teknik SuperMAC for 96 kHz digital audio and control
-
Ultranet output for up to 16 channels of Powerplay P16 personal monitoring
-
Secondary AES50 port for daisy-chaining additional stage boxes or personal mixers
-
Rack-mountable 1U metal chassis with integrated ears and up to 100 m cable runs
Technical Specifications
| Specification | Detail |
|---|---|
| Inputs | 32 × XLR mic inputs with recallable Midas preamps (+5 to +60 dB gain) |
| Phantom Power | +48 V on each input with LED indicator |
| Pad | Switchable –20 dB on each input |
| Outputs | 16 × balanced XLR line outputs (relay protected) |
| Network | 1 × AES50 port (SuperMAC technology) |
| Ultranet | 1 × Ultranet port for Powerplay P16 |
| Expansion | 1 × secondary AES50 port |
| Sampling Rate | 96 kHz audio processing |
| Latency | < 2 ms end-to-end |
| Rack Units | 1U, rack-mountable |
| Remote Distance | Up to 100 m over Cat5e/6 cable |
| Power Supply | Internal universal 100–240 VAC, IEC inlet |
